The production and installation of purification ventilation ducts and components, and the calculation method of engineering quantity is the same as that of general ventilation ducts, using corresponding norms. However, for the installation of components, purification fees need to be calculated, with 35% of the corresponding component sub item installation base price as the purification fee, of which labor costs account for 40%. The cost of the essence sealing treatment between the purification pipeline and the building gap shall be calculated according to the actual situation.

圆形风管展开面积，不扣除检查孔、测定孔、送风口、吸风口等所占面积，咬口重叠所占面积，咬口重叠部分也不增加。

The unfolded area of a circular air duct does not deduct the area occupied by inspection holes, measuring holes, air supply outlets, suction outlets, etc. The area occupied by overlapping bites does not increase, nor does the overlapping part of bites increase.

风管制作安装定额中发兰垫料是按各种材料品种综合考虑的，不得换算。

The flange gasket material in the production and installation quota of air ducts is comprehensively considered based on various material types and cannot be converted.

整个通风系统设计采用渐缩管均匀送风者，圆形管按断面平均直径，矩形管按断面平均周长套用相应规定子目，其人工乘以系数2.5。空气幕送风管制作安装，按矩形风管断面平均周长套用相应风管规定子目，其人工成以系数3.0，期于不变。

The entire ventilation system is designed with uniform air supply through gradually reducing pipes. Circular pipes are designed according to the average diameter of the cross-section, while rectangular pipes are designed according to the average circumference of the cross-section using corresponding sub items. The labor force is multiplied by a coefficient of 2.5. The production and installation of air curtain air supply pipes shall be carried out according to the average circumference of the rectangular air duct section, and the corresponding sub items of the air duct shall be applied. The labor cost coefficient shall be 3.0, and the period shall remain unchanged.

风管长度计算，一律以施工图所示线长度为准，包括弯头、三通、变径管、天圆地方管件长度。支管长度以支管线与主管线交接点为分界点。

The calculation of the length of the air duct shall be based on the centerline length shown on the construction drawing, including the length of elbows, tees, variable diameter pipes, and pipe fittings in circular areas. The length of the branch is divided by the intersection point between the centerline of the branch and the centerline of the main pipe.

风管制作材料的品种、规格、性能与厚度应符合设计图纸和现行产品标准的规定。

The variety, specifications, performance, and thickness of air duct production materials should comply with the design drawings and current national product standards.

制作质量要求：

Production quality requirements:

风管的规格、尺寸符合设计要求；

The specifications and dimensions of the air duct meet the design requirements;

风管外观质量应达到折角平直，圆弧均匀，两端面平行，无翘角；

The appearance quality of the air duct should be flat and straight with uniform arcs, parallel at both ends, and no warping angles;

风管的内表面要做到表面光滑，严禁有横向拼缝和在管内设加固筋或采用凸棱加固方法。尽量减少底部的纵向拼缝。矩形风管底边小于800mm时，底边不得有纵向拼缝。所有的螺母、螺栓、垫圈和铆钉均应采用与管材性能匹配，采用不会产生电化学腐蚀的材料，或采用镀锌等；洁净风管的咬口缝连接紧密，宽度均匀，无孔洞，半咬口及胀裂现象。

The inner surface of the air duct should be smooth, and it is strictly prohibited to have horizontal seams or install reinforcement bars or use convex reinforcement methods inside the duct. Minimize the longitudinal seams at the bottom as much as possible. When the bottom edge of a rectangular air duct is less than 800mm, there shall be no longitudinal seam at the bottom edge. All nuts, bolts, washers, and rivets should be made of materials that match the performance of the pipe material and do not cause electrochemical corrosion, or galvanized; The bite seam of the clean air duct is tightly connected, with a uniform width and no holes, semi bite, or expansion cracks.
