In ventilation engineering, the fabrication and installation of ventilation pipes is an important link. What are the specific requirements and specifications for the fabrication and installation methods? This is what all individuals or enterprises processing ventilation pipes and undertaking ventilation engineering should study and learn. In the fabrication and installation of ventilation pipes, there are mainly the following requirements and specifications:

1通风管道制作方法，要求及规范

1. Fabrication method, requirements and specifications of ventilation pipe

1、通风、空气调节工程所使用的主要材料、设备、成品半成品等均应有出厂合格证明书或质量鉴定文件。

1. The main materials, equipment, finished products and semi-finished products used in ventilation and air conditioning projects shall be provided with factory certificate or quality appraisal documents.

2、圆形风管的三通，其夹角为90º。

2. Tee of circular air duct with an included angle of 90 º.

3、通风工程必须按批准的设计图纸施工。

3. The ventilation works must be constructed according to the approved design drawings.

4、通风管道制作的尺寸应按图施工，均以内径为准，连接管应与阀体相吻合。

4. The size of the ventilation pipe shall be constructed according to the drawing, and the inner diameter shall prevail, and the connecting pipe shall be consistent with the valve body.

5、风管各管段的连接应采用可拆卸的形式。

5. The connection of each pipe section of the air duct shall be in a detachable form.

6、圆形弯管的弯曲半径和少节数及矩形弯管的弯曲半径应按《建筑安装工程施工技术操作规程》中有关规定执行。

6. The bending radius and small number of sections of circular bends and the bending radius of rectangular bends shall be in accordance with the relevant provisions of the technical operation specification for construction and installation engineering.

7、风管厚度按标准。

7. The thickness of air duct shall be in accordance with the standard.

通风管道的安装准备工作

Preparation for installation of ventilation duct

1、部件安装前应进行如下检查，经检查合格并填写有关验收资料后方可进行安装：

1. The following inspections shall be carried out before component installation. Installation can be carried out only after passing the inspection and filling in relevant acceptance data:

1）各类阀门制作应牢固，调节制动装置应准确灵活、可靠，并标明阀门启闭方向，防火阀壳体厚度应大于等于2mm，材料选用应符合GB50243-97规范要求。西安通风管道制作厂家

1) All kinds of valves shall be firmly manufactured, the adjusting and braking device shall be accurate, flexible and reliable, and the opening and closing direction of the valve shall be marked. The thickness of the fire damper shell shall be greater than or equal to 2mm, and the material selection shall meet the requirements of GB50243-97. Xi'an ventilation pipe manufacturer

2）风口表面应平整，偏差<=2mm，矩形风口对角线差<=3mm，圆形风口任意正交两直径的允许偏差<=2mm。

2) The tuyere surface shall be flat with deviation < = 2mm, the diagonal difference of rectangular tuyere is < = 3mm, and the allowable deviation of any two orthogonal diameters of circular tuyere is < = 2mm.

3）风口各转动部分应灵活，叶片或插板应平直，叶片内距应均匀，散流器和调节应同轴，轴向间距分布匀称，叶片等启闭应完全，人防密闭阀方向与冲击波相准确，不可装反，叶片全开或全闭，不可作调节风量之用。

3) The rotating parts of the air outlet shall be flexible, the blades or insert plates shall be straight, the inner distance of the blades shall be uniform, the diffuser and regulator shall be coaxial, the axial spacing shall be evenly distributed, the opening and closing of the blades, etc. shall be complete, the direction of the civil air defense sealing valve shall be accurate with the shock wave, and shall not be installed reversely. The blades shall be fully opened or closed, and shall not be used to adjust the air volume.

4）柔性短管人防滤毒系统选用橡胶型，其他选用三防防火帆布，各吊、支、托架，应平整牢固，焊缝饱满，抱箍的圆弧应均匀。

4) The flexible short pipe civil air defense and virus filtering system shall be of rubber type, and the others shall be of three prevention and fire canvas. All cranes, supports and brackets shall be flat and firm, the welds shall be full, and the arc of hoop shall be uniform.
