厨房内油烟净化器的安装注意事项
1、每个炉灶对应的处理风量约为2000~2500m3/h，根据炉灶数量及安装位置确定总的处理风量并选定相应的净化器的规格型号。
The handling air volume corresponding to each stove is about 2000~2500m3/h. According to the number and location of the stove, the total amount of air is determined and the corresponding specification of the purifier is selected.
2、净化器可室内、外安装，净化器室外安装请在机器上方安装防雨装置以增加机器的使用寿命，净化器周围需要预留维修空间、机箱门应有90度以上直角自由开启空间以便于日后保养、清洗、维修。
the purifier can be installed indoors and outside, and the cleaner is installed outside the machine to increase the service life of the machine. The maintenance space should be reserved around the purifier, and the box door should be free to open space above 90 degrees to facilitate the maintenance, cleaning and maintenance.
3、机器在安装前好先通电试行一段时间，检验机器的电极是否会在运输或搬运中产生偏移。
before the installation of the machine, it is better to test the machine for a period of time and check whether the electrode of the machine will be offset in transportation or transportation.
4、机器的进出风口可以随意互换，进风口方向必须要有过滤网。
the inlet and outlet of the machine can be exchanged at will, and the inlet must have a filter screen.
5、安装油烟净化器与烟罩出口位置的距离少在4米以上，以确保消防和净化效果；净化器与风机的距离在2米以上比较合适，净化器好安装在风机的前面，如果风机需要安装在净化器的前面，风机的出风口不能对着净化器直吹，否则会影响净化器净化效果；净化器的进风口好不能有弯头。
The distance between the oil fume purifier and the exit position of the hood is at least 4 meters above, to ensure the safety and purification effect. The distance between the purifier and the fan is more suitable than 2 meters. The purifier is best installed in front of the fan. If the fan needs to be installed in the front of the purifier, the outlet of the fan can not be treated with the purifier. The blows are directly blown, otherwise the purifier's purge effect will be affected; the inlet of the purifier should not have elbow.
6、设备箱体必须接地。
the equipment box must be safely grounded.
7、接好排油管。Connect the oil exhaust pipe well.
8、选择相匹配的风机风量，风机的风量选择一般与净化器的处理风量相当。风机的风量在满足厨房抽风要求的情况下，风机的风量越小对净化器的效果就越好。
choose matching fan air volume, and the air volume of fan is generally equal to that of purifier. When the air volume of the fan satisfies the requirements of the kitchen exhaust, the smaller the air volume of the fan is, the better the purifier will be.
9、净化器通过发兰与排风风管连接，所有连接应密封、防止漏油。
The purifier is connected by FA LAN and exhaust air duct. All connections should be sealed to prevent oil leakage.
10、确保，净化器要求能与风机联动，即净化器跟风机同时开同时关；如不能联动的，应做到在启动净化器之前必须先启动风机运作10余分钟，关机时应先关掉净化器后再停风机。
to ensure safety, the purifier requires a linkage with the fan, that is, the purifier and the fan at the same time; if not linked, should start before starting the purifier to start the fan operation for more than 10 minutes, when the machine is shut down, the purifier should be turned off and then the fan.
