油烟净化器采用撞针式连接的好处

来源:http://www.jnqsg.com/     发布时间:2017-07-19

  在油烟净化器的放电电场异极间具有10-15千伏特的电位差,使不导电的气体分子经分解或电子附着成为自由离子。当气流通过收尘电场区域时,粒子经离子撞击带电而移向具相反电性的收集电极。换言之,收集机制的步使气体离子化,第二步使气流中的粒子带电。第三步使粒子撞击收集电极板而被收集。

  In a soot purifier, the electric field of the soot purifier has a potential difference of 10-15 kV between the poles of the soot purifier, so that the free gas molecules are decomposed or electronically attached to free ions. When the airflow passes through the dust collecting electric field, the particles move electrically to the collecting electrode with the opposite electrical charge. In other words, the first step in the collection mechanism is to ionize the gas, and the second step is to make the particles in the stream live. The third step is to cause particles to hit the collecting electrode plates and to be collected.

  理论上,分离带电粒子的电力与粒子带电量及收集电场强度之积成正比。此电力的大小,就比重为1的l微米粒子而言,为重力的3000倍:就比重为l的10微米粒子面言,为重力的300倍,此为油烟净化器能与率的原因。

  In theory, the power of a charged particle is proportional to the amount of charged particles and the strength of the electric field gathered. The size of the power is 3000 times the gravity of the L micron particle with a specific weight of 1: the 10 micron particle size of L is 300 times the gravity, which is the reason for the high efficiency and high efficiency of the soot purifier.

  1、电场模块化设计制作,组合方便,可按风量拼装成型,拆装便利,检修方便。
济南通风管道工程

  1. The electric field modular design makes, the assembly is convenient, may assemble by the air volume, the assembly and disassembly is convenient, the overhaul is convenient.

  2、的电场设计,精密、牢固的蜂窝式电场结构,360度无死角,使电场与油烟粒子结合作用的时间更长,净化更完全。

  2, advanced electric field design, precise and firm honeycomb type electric field structure, 360 degrees without dead angle, make electric field combine with lampblack particle longer, purify more completely.

  3、进出风口可随意互换,方便现场安装需要(出厂时机器的进出风口已经设置好,如

  3. The air inlet and outlet can be interchanged at will. It is convenient for installation on site. (factory) the air inlet and outlet of the machine have been set up, such as

  有需调配时请参考安装方法)。

  Please refer to the installation method when it is necessary to deploy.

  4、采用撞针式连接,系数高,更好的高压连接设计,开门时电场会自动断电。

  4, the firing pin type connection, high safety coefficient, design a better connected pressure, open the door when the electric field will automatically power off.

  5、净化效率高,运行稳定,去除率高于85%,能去除大部分气味。

  5, high purification efficiency, stable operation, removal rate is higher than 85%, can remove most of the odor.

  本文由油烟净化器为您提供,我们的网站是:http://www.jnqsg.com/我们将以全心全意的热情为您提供更的服务,欢迎您的访问!

  This article is provided by the lampblack purifier, our website is: http://www.jnqsg.com/, we will wholeheartedly provide you with better service, you are welcome to visit!
